Industrial Precision Air Filter Hanksion Filters High Quality Water, Oil and Dust Removal, Air Line Filter, Oil-Water Separation
  • Industrial Precision Air Filter Hanksion Filters High Quality Water, Oil and Dust Removal, Air Line Filter, Oil-Water Separation
  • Industrial Precision Air Filter Hanksion Filters High Quality Water, Oil and Dust Removal, Air Line Filter, Oil-Water Separation

Industrial Precision Air Filter Hanksion Filters High Quality Water, Oil and Dust Removal, Air Line Filter, Oil-Water Separation

FOB Reference Price Purchase quantity (Piece(s))

>= 100 Piece(s)

US $6.50

Minimum order quantity100 Piece(s)
PaymentT/T,Other
-
+
Inquiry
ADD TO CART
  • OVERVIEW
  • SPECIFICATIONS
  • OTHER

C-grade Main Pipeline Filter:
Efficiently filtrate bulk liquid and solid particles above 3μm.
The minimum residual oil content≤ 5ppm, consist of a little moisture, dust and oil vapor.
The best position suggested to be put behand of the air compressor and rear cooler, ahead of other matched filters, for general protection; or ahead of refrigerant air dryer as a pretreatment device.


T-grade Air line filter:
Efficiently filtrate 1μm-size liquid and solid particles
The minimum residual oil content ≤ 0.5ppm, consist of little moisture, dust and oil vapor.
The best position suggested to be put ahead of A-rank filter for pre-processing; or behand of the refrigerant air dryer and desiccant air dryer, to improve air quality.


A-grade Ultra-efficient Deoil Filter:
Efficiently filtrate 0.01μm-size liquid and solid particles.
The minimum residual oil content ≤ 0.001ppm, almost all moisture, dust and oil vapor are removed.
The best position suggested to be put ahead of H-grade filter and desiccant air dryer for safety; or behand of the refrigerant air dryer to ensure no oil in air outlet.


H-grade Activated Carbon Micro Oil Vapor Filter:
Efficiently filtrate 0.01um-size oil vapor and hydrocarbons.
The minimum residual oil content ≤ 0.003ppm, no moisture, dust and oil existed, odorless and tasteless.
Make a function of final filtering. For special industry demanding for high-quality air to use, such as food industry, respiratory product, aseptic packaging, etc.


Features:
Enlarged flow area reduce pressure drop
Manufactured from top quality aluminum ailoy and carbon steel.
Threaded and flanged type connection,air flow direction indicated on the housing,easyto install.
Epoxy powder painted(interio and exterior) for improvement of durability and corrosion resistance.
Differential pressure indicator indicates optimum time for element change to maximize the utilization of element while minimizing pressure drop.
Level indicator allows visual monitoring of liquid level and signals the need for preventative maintenance to avoid downstream contamination.
Auto drain is reliable to discharge liquid without blocking as well as durability.
